Wheel Spacers
- Lightweight yet strong polymer design engineered for vertical reinforcement applications.
- Secure locking hub keeps the spacer firmly in place during steel placement and concrete pouring.
- Minimal contact surface ensures reduced friction and cleaner formwork finish.
- Open spoke design allows free and uninterrupted concrete flow around reinforcement.
- Suitable for steel bar diameters between 6 mm and 20 mm.
- Designed to deliver consistent cover and maximize load-bearing performance.
- Precision-molded for dimensional accuracy and product consistency.
Expert Quality Check
Free Shipping
Hassle-Free Warranty
Customer Support
Lightweight Precision for Vertical Reinforcement
GSPF Wheel Spacers are engineered to provide reliable and stable cover for vertical precast and in-situ concrete applications. Their lightweight yet durable polymer construction ensures strong support while minimizing overall structural load. The integrated locking hub firmly secures the spacer to the reinforcement bar, preventing slippage or movement during assembly and concrete pouring.
Designed with an open spoke structure, these spacers promote unimpeded concrete flow, ensuring complete encapsulation of reinforcement for superior structural performance. Minimal formwork contact reduces marking and provides a clean finish, making Wheel Spacers ideal for high-precision precast operations and demanding construction environments.
Technical Specifications
| Product Code | Cover (mm) | Steelbar (mm) | Packing (pcs) |
|---|---|---|---|
| GWS20 | 20 | 6-18 | 1500 |
| GWS25 | 25 | 6-18 | 1000 |
| GWS30 | 30 | 6-18 | 750 |
| GWS40 | 40 | 6-18 | 600 |
| GWS50 | 50 | 6-18 | 300 |
| GWS60 | 60 | 6-18 | 250 |
| GWS75 | 75 | 6-20 | 200 |
Product Applications
Wheel Spacers are engineered specifically for vertical reinforcement scenarios where secure positioning, clean formwork finishes, and uninterrupted concrete flow are essential. Their lightweight construction and locking system make them effective for both precast plant production and on-site applications.
These spacers are ideal for structures requiring precise vertical alignment and high-quality surface results.
- Vertical precast concrete elements
- Columns, walls, and structural cores
- Reinforcement cages requiring stable vertical spacing
- High-finish architectural precast components
- In-situ concrete works requiring minimal formwork contact
- Projects with strict quality and structural compliance requirements
Why GSPF?
GSPF Wheel Spacers are manufactured using advanced polymer technology and precision tooling to ensure consistent performance across every batch. With a design optimized for stability, concrete flow, and minimal formwork contact, these spacers deliver exceptional results in both precast and on-site conditions. Our UAE-based facility ensures dependable regional supply, strict quality control, and technical support to help you choose the right spacer for your application – reinforcing GSPF’s commitment to reliability and engineering excellence.
